Author: Subject: Sierra Steer_Col_Switches - Spring Clip Thingy??
Dick Axtell

posted on 20/7/19 at 03:04 PM Reply With Quote
Sierra Steer_Col_Switches - Spring Clip Thingy??

Hello Locosters and - (b)(I)HELP(/I)(/b)

After working on my dashboard, replacing a fuel gauge, refixing wiring etc., I am now in the process of putting everything back together. Have re-fitted the steering column indicator and light switches. Have forgotten exactly what goes where, with some smaller parts.

In particular, the "inverted W shaped" spring thingy, which I've shown in the attached image. Should it sit inside the switches, or sit astride them? Your help/advice would be much appreciated.

Col_Switches_Spring
Col_Switches_Spring






Work-in-Progress: Changed to Zetec + T9. Still trying!!

View User's Profile Visit User's Homepage View All Posts By User U2U Member
jwallbank

posted on 20/7/19 at 04:47 PM Reply With Quote
Spring clip thingy

I've found a drawing in the Sierra Manual that may be of help. Looks like a slightly different model than yours but might help.

Not been successful at inserting it in the reply but have a look in my photo archive - Misc section, it's in there.

John W

View User's Profile E-Mail User View All Posts By User U2U Member
Dick Axtell

posted on 20/7/19 at 07:46 PM Reply With Quote
Hi John W. Thanks for your reply. That diagram (image 121844), is very helpful.





Work-in-Progress: Changed to Zetec + T9. Still trying!!

View User's Profile Visit User's Homepage View All Posts By User U2U Member
big_wasa

posted on 21/7/19 at 01:48 PM Reply With Quote
Mounts across the two top bolts of the switch gear.


View User's Profile View All Posts By User U2U Member
Dick Axtell

posted on 21/7/19 at 02:33 PM Reply With Quote
quote:
Originally posted by big_wasa
Mounts across the two top bolts of the switch gear.




Thanks for this very useful image. All is now clear (as far as these switches are concerned!!).





Work-in-Progress: Changed to Zetec + T9. Still trying!!

View User's Profile Visit User's Homepage View All Posts By User U2U Member
gremlin1234

posted on 21/7/19 at 03:05 PM Reply With Quote
quote:
Originally posted by jwallbank
Not been successful at inserting it in the reply but have a look in my photo archive - Misc section, it's in there.


find the picture in your archive, and copy the 'forum code' it looks like "[pg!]121844[/pg!]" but without the ! marks
Description
Description

View User's Profile View All Posts By User U2U Member
jwallbank

posted on 21/7/19 at 03:29 PM Reply With Quote
Thanks for that, not sure what I was doing wrong!

Description
Description

View User's Profile E-Mail User View All Posts By User U2U Member
